Part Number
IDN1385310D80Z0
Model
IDNext 1385 SBCL "Univ"
Operating Temperature
-20...55 °C (-4...131 °F)
Storage Temperature
-30...85 °C (-22...185 °F)
Ambient Humidity
10...90 %RH (non-condensing)
Power Supply
SMPS 100...240 Vac (±10 %) 50/60 Hz
Power Draw
3.5 W / 8.5 VA
N. Analogue Inputs
4
Analogue Inputs
2x NTC/PTC/Pt1000, 2x NTC/PTC/Pt1000 or digital inputs
N. Digital Inputs
3
Digital Inputs
1x voltage-free, 2x voltage-free or analog input
N. Analogue Outputs
0
N. Digital Outputs
4
Digital Outputs
2x 10(6) A - 5 A (70 A inrush, 2,5 ms); 1x NO 8(4) A / NC 6(3) A / CO 6 A resistivi; 1x 5(2) A - 1 A (25 A inrush, 2,5 ms). Load expressed in compliance with Standard IEC/UL61810-1, Clause D.3 Special loads with inrush current
Display Range
-199.9…199.9 °C o -1999…1999 °C
Display
LED 3 digits 1/2 + sign
Resolution
1 °C or 0.1 °C (depending on the display range setting)
Measurement Range
NTC: -50...110°C (-58...230°F); PTC: -55...140 °C (-67...284 °F); Pt1000: -80...150 °C (-112...302 °F)
Accuracy
NTC: -50...-30 °C (-58...-22 °F) better than ±2.4 °C (±4.3 °F) ±1 digit and -30...110 °C (-22...230 °F) better than ±1.6 °C (±2.9 °F) ±1 digit; PTC: -55...140 °C (-67...284 °F) better than ±2.0 °C (±3.5 °F) ±1 digit; Pt1000: -80...-55 °C (-112...-67 °F) better than ±1.2 °C (±2.2 °F) ±1 digit and -55...150 °C (-67...302 °F) better than ±2.3 °C (±4.1 °F) ±1 digit
N. Serial Ports
3
Serial Ports
1x serial port RS485, 1x TTL, 1x Field Bus
Weight (g) Net
170
Width (L) Net
81
Height (Ht) Net
35
Depth (P) Net
94
MOQ
60
