Part Number
IDN1385310180Z0
Model
IDNext 1385 SBCL "Univ"
Operating Temperature
-20...55 °C (-4...131 °F)
Storage Temperature
-30...85 °C (-22...185 °F)
Ambient Humidity
10...90 %RH (non-condensing)
Power Supply
SMPS 100...240 Vac (±10 %) 50/60 Hz
Power Draw
3.5 W / 8.5 VA
N. Analogue Inputs
4
Analogue Inputs
2x NTC/PTC/Pt1000, 2x NTC/PTC/Pt1000 or digital inputs
N. Digital Inputs
3
Digital Inputs
1x voltage-free, 2x voltage-free or analog input
N. Analogue Outputs
0
N. Digital Outputs
4
Digital Outputs
2x 10(6) A - 5 A (70 A inrush, 2,5 ms); 1x NO 8(4) A / NC 6(3) A / CO 6 A resistivi; 1x 5(2) A - 1 A (25 A inrush, 2,5 ms). Load expressed in compliance with Standard IEC/UL61810-1, Clause D.3 Special loads with inrush current
Display Range
-199.9…199.9 °C o -1999…1999 °C
Display
LED 3 digits 1/2 + sign
Resolution
1 °C or 0.1 °C (depending on the display range setting)
Measurement Range
NTC: -50...110°C (-58...230°F); PTC: -55...140 °C (-67...284 °F); Pt1000: -80...150 °C (-112...302 °F)
Accuracy
NTC: -50...-30 °C (-58...-22 °F) better than ±2.4 °C (±4.3 °F) ±1 digit and -30...110 °C (-22...230 °F) better than ±1.6 °C (±2.9 °F) ±1 digit; PTC: -55...140 °C (-67...284 °F) better than ±2.0 °C (±3.5 °F) ±1 digit; Pt1000: -80...-55 °C (-112...-67 °F) better than ±1.2 °C (±2.2 °F) ±1 digit and -55...150 °C (-67...302 °F) better than ±2.3 °C (±4.1 °F) ±1 digit
N. Serial Ports
3
Serial Ports
1x serial port RS485, 1x TTL, 1x Field Bus
Weight (g) Net
150
Width (L) Net
81
Height (Ht) Net
35
Depth (P) Net
95
MOQ
6
The Environmental Data Program classifies and measures the environmental characteristics and footprint of products. The program aims to provide environmental data on products, using a fact-based methodology.
Environmental footprint
Carbon footprint (kg CO2 eq. Total Life cycle)
152
Environmental Disclosure
Use Better
Materials and Substances
Packaging made with recycled cardboard
Yes
Packaging without single use plastic
Yes
EU RoHS Directive
Product compliant, please contact Technical Support
SCIP Number
55c09e5e-71c1-4b98-b341-3bce6dfdc8c7
REACh Regulation
Product compliant, please contact Technical Support
California Proposition 65
WARNING: This product can expose you to chemical including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Use Again
Repack and remanufacture
Circularity Profile
WEEE Label
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
